Dell Workstation Precision T3500 Xeon 3500 & 5600
- Κατηγορία
- Xeon 5400, 5500, 5600, 3500 &3600 Series
- Operating System
- Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- Intel X58
- Processors
- Intel Xeon 5600 series processors up to six-cores with up to 6.4GT/s
- Memory Support
- Up to 24GB 1333MHz ECC and non-ECC memory in 6 DIMM slots
- Hard Drive
- SATA 3.0GB/s 7200RPM SATA 3.0GB/s 10K RPM Up to 2.0TB
- Removable Media
- CD-RW/DVD Combo; DVD-ROM; DVD+/-RW; Blu-ray; USB Floppy Drive; USB media card reader
- Expansion Bays
- Two internal 3.5" HDD bays; two external 5.25" optical bays, one external 3.5" flex bay
- Expansion Slots
- Two PCIe x8 slot wired as x4 (half-length); two PCIe x16 Gen 2 graphics slots; two PCI slots
- Graphics
- Support for 2 PCI Express x16 Gen 2 graphics cards up to 150W.
- Audio
- Integrated High Definition Audio
- Communications
- Integrated Broadcom? 5761 Gigabit Ethernet controller
- I/O Ports
- Eleven USB 2.0: two front, six rear, three internal; One serial; One parallel; Two PS/2; Mic and headphone, line-in and line-out
- Input Devices
- USB: Dell QuietKey, Enhanced Multimedia, Smartcard Reader keyboard; Bluetooth Keyboard and Mouse
- USB
- Dell two-button mechanical with scroll, Dell two-button optical with scroll
- Power
- 525W
- Dimensions
- 44.7 x 17.2 x 46.8 cm
- Weight
- N/A
Dell Workstation Precision T7400 Xeon 5200 & 5400
- Κατηγορία
- Xeon 5400, 5500, 5600, 3500 &3600 Series
- Operating System
- Windows 7 Home & Pro. MAR, Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- Intel? 5400 chipset
- Processors
- Dual-core Intel? Xeon? 5200 series processors; Quad-core Intel? Xeon? 5400 series processors;
- Memory Support
- Up to 64GB1 quad-channel 667MHz ECC and 800MHz ECC memory; Up to 16 DIMM slots;
- Hard Drive
- SATA 3.0Gb/s 7200 RPM 16MB up to 1.0TB; SATA 3.0Gb/s 10K RPM 16MB up to 160GB; SAS 15K RPM up to 300GB
- Removable Media
- CD-RW/DVD Combo, DVD-ROM, DVD+/-RW, Blu-ray, USB Floppy Drive, USB media card reader
- Expansion Bays
- Four internal 3.5? hard disk drive bays; Three external 5.25? optical bays; One external 3.5? flex bay
- Expansion Slots
- One PCI-e x8 slot wired as x4; Two PCI-e x16 Gen 2 slots; Three PCI-X 64bit/100MHz slots, One PCI 32bit slot;
- Graphics
- Support for 2 PCI Express x16 Gen 2 graphics cards up to 225 watts
- Audio
- Integrated High Definition Audio
- Communications
- Integrated Broadcom? 5754 Gigabit Ethernet controller
- I/O Ports
- Front: Two USB 2.0, Mic/Headphone; Rear: Five USB 2.0, Two PS2, Two Serial, Audio I/O
- Input Devices
- Dell Enhanced QuietKey USB; Enhanced Multimedia USB; Smart Card keyboard USBDell USB two-button mouse and Dell USB optical two-button scroll mouse
- Power
- 980 watt 80%+ Efficiency Power Factor Correcting (PFC) power supply
- Dimensions
- (WxHxD) 8.5? x 22.26? x 22.3?, 21.59cm x 56.54cm x 56.6cm
- Weight
- N/A
Dell Workstation Precision T1650 E3-1200v2
- Κατηγορία
- Tower
- Operating System
- Windows 7 Home & Pro. MAR, Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- Intel C216 Chipset
- Processors
- Intel? Xeon? Processor E3-1200v2 Family; 3rd generation Intel? Core? i7 and i5; 2nd generation Intel Core i3
- Memory Support
- Up to 32GB 1600MHz ECC or 16GB non-ECC DDR3 memory; 4 DIMM slots
- Hard Drive
- Up to two 3.5" SATA drives: 250GB, 500GB, 1TB, 2TB; Or up to four 2.5" SATA drives: 320GB, 500GB
- Removable Media
- Up to two optional optical drives: DVD-ROM; DVD+/-RW; BD-RE
- Expansion Bays
- Two internal 3.5" hard drive bays; two external 5.25" optical bays
- Expansion Slots
- One PCIe x16 Gen 3; one PCIe x16 Gen 2 wired x4; one PCIe x1; One PCI 32bit/33MHz
- Graphics
- Support for one PCI Express? x16 Gen 3 graphic card up to 75W (total for graphics)
- Audio
- Integrated Realtek ALC269VB High Definition Audio
- Communications
- Integrated Intel 82579 Gigabit Ethernet controller
- I/O Ports
- Front: Two USB 2.0, Two USB 3.0, Mic/Headphones; Rear: Four USB 2.0, Two USB 3.0, VGA, DP, Serial. Two PS2, Audio I/O
- Power
- 320W 90% efficient (80 Plus? Gold Certified); 275W 65% efficient
- Dimensions
- (HxWxD) 14.17" x 6.89" x 17.13"; 360mm x 175mm x 435mm
- Weight
- N/A
Dell Workstation Precision T1700 i3,i5,i7 4th Gen & E3-1200v
- Κατηγορία
- Xeon E3, E5 v3 & v4 Series
- Operating System
- Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- Intel C226 Chipset
- Processors
- Intel Xeon Processor E3-1200 v3 Family; 4th generation Intel Core i7 and i5
- Memory Support
- Up to 32GB 1600MHz ECC; up to 16GB 1600MHz non-ECC DDR3 memory; 4 DIMM slots
- Hard Drive
- Up to two 3.5" SATA drives: 250GB, 500GB, 1TB, 2TB; Or up to four 2.5" SATA drives: 320GB, 500GB
- Removable Media
- Up to two optional optical drives: DVD-ROM; DVD+/-RW; Optional 19-in-1 media card reader
- Expansion Bays
- Two internal 3.5" bays; two external 5.25" optical bays
- Expansion Slots
- One PCIe x16 Gen 3; one PCIe x16 Gen 2 wired x4; one PCIe x1; One PCI 32bit/33MHz
- Graphics
- Support for one PCI Express x16 Gen 3 graphic card up to 150W (total for graphics)
- Audio
- Integrated Realtek ALC269Q High Definition Audio
- Communications
- Integrated Intel 82579 Gigabit Ethernet controller
- I/O Ports
- Front: Two USB 2.0, Two USB 3.0, Mic/Headphones; Rear: Four USB 2.0, Two USB 3.0, VGA, DP, Serial. Two PS2, Audio I/O
- Power
- 365W 90% efficient (80 Plus Gold Certified); 290W 65% efficient
- Dimensions
- HxWxD: 14.17" x 6.89" x 17.13" / 360mm x 175mm x 435mm
- Weight
- N/A
Dell Workstation Precision T3600 E5-1600 & E5-2600
- Κατηγορία
- Tower
- Operating System
- Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- Intel C600 series chipset
- Processors
- Intel Xeon processor E5-1600 or E5-2600 family with up to eight-cores
- Memory Support
- Quad channel; Up to 64GB 1600MHz or 1333MHz ECC and non-ECC DDR3 memory; 4 DIMM slots
- Hard Drive
- SATA 7200RPM Up to 3.0TB, SSD Up to 256GB
- Removable Media
- Slimline options: DVD-ROM; DVD+/-RW; BD-RE; Optional 5.25" device: DVD+/-RW, 19-in-1 media card reader
- Expansion Bays
- Two internal 3.5" hard drive bays; one external 5.25" bay; one external slimline optical bay
- Expansion Slots
- Two PCIe x16 Gen 3; one PCIe x16 Gen 3 wired x4; one PCIe x4 Gen 2; one PCIe x1 Gen 2; One PCI 32bit/33MHz
- Graphics
- Support for two PCI Express? x16 Gen 2 or Gen 3 graphics cards up to 300W
- Audio
- Integrated Realtek ALC269Q High Definition Audio
- Communications
- Integrated Intel 82579 Gigabit Ethernet controller
- I/O Ports
- Front three USB 2.0, One USB 3.0, Mic/Headphone; Rear: Five USB 2.0, One USB 3.0, One Serial, Two PS2
- Input Devices
- USB: Dell QuietKey, Enhanced Multimedia, Smartcard Reader keyboard; Bluetooth Keyboard and Mouse, USB: Dell two-button mechanical with scroll, Dell two-button optical with scroll
- Power
- 80 Plus Gold Certified, 90% efficient): 635W or 425W
- Dimensions
- 414 x 471 x 172.6 mm
- Weight
- N/A
Dell Workstation Precision T5610 Xeon E5-2600v2
- Κατηγορία
- Tower
- Operating System
- Windows 7 Home & Pro. MAR, Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- Intel? C602
- Processors
- One or two; Intel? Xeon? processor E5-2600 v2 family with up to ten cores
- Memory Support
- Quad channel; Up to 128GB 1866MHz ECC RDIMM memory; 8 DIMM slots (4 per processor)
- Hard Drive
- SATA 7200RPM Up to 3TB, SAS 10K RPM Up to 900GB, SSD Up to 512GB
- Removable Media
- Slimline options: DVD-ROM; DVD+/-RW; BD-RE; Optional 5.25" device: DVD+/-RW, 19-in-1 media card reader
- Expansion Bays
- One external slimline optical bay; Two internal 3.5" hard drive bays; one external 5.25" bay
- Expansion Slots
- Two PCIe x16 Gen 3; one PCIe x16 Gen 3 wired x8 (HL); one PCIe x16 Gen 2 wired x4; one PCIe x1 Gen 2; One PCI 32bit
- Graphics
- Support for two PCI Express? x16 Gen 2 or Gen 3 graphics cards up to 300W
- Audio
- Integrated Realtek ALC269Q High Definition Audio
- Communications
- Intel 82579 Gigabit Ethernet controller
- I/O Ports
- Front: Three USB 2.0, One USB 3.0, Mic/Headphone; Rear: Three USB 2.0, Three USB 3.0, Two PS2, One Serial
- Input Devices
- USB: Dell QuietKey, Enhanced Multimedia, Smartcard Reader keyboard; Bluetooth Keyboard and Mouse
- USB
- Dell two-button mechanical with scroll, Dell two-button optical with scroll
- Power
- 80 Plus? Gold Certified, 90% efficient): 825W or 685W
- Dimensions
- (HxWxD): 16.30 x 6.79 x 18.54"; 414 x 172.6 x 471mm
- Weight
- N/A
Dell Workstation Precision T7600 Xeon E5-2600
- Κατηγορία
- Tower
- Operating System
- Windows 7 Home & Pro. MAR, Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- Intel? C600 series
- Processors
- One or two; Intel? Xeon? processor E5-2600 family with up to eight cores
- Memory Support
- Quad channel; up to 512GB 1600MHz or 1333MHz ECC RDIMM memory; 16 DIMM slots (8 per processor)
- Hard Drive
- SATA 7200 RPM up to 3TB; SAS 15K up to 146GB; SAS 10K RPM up to 900GB; SSD up to 256GB
- Removable Media
- CD-RW/DVD Combo, DVD-ROM, DVD+/-RW, Blu-ray, USB Floppy Drive, USB media card reader
- Expansion Bays
- One external slimline optical bay; One external 5.25" bay; Four 3.5" or eight 2.5" hard drive bays;
- Expansion Slots
- Two PCIe x16; two additional PCIe x16; one PCIe x16 (x4); one PCIe x16 Gen 2 (x4); One PCI 32bit
- Graphics
- Support for up to three PCI Express? x16 Gen 2 or Gen 3 graphics cards up to 675W
- Audio
- Integrated Realtek ALC269Q High Definition Audio
- Communications
- Integrated Intel 82579 and Intel 82754 Gigabit Ethernet controllers
- I/O Ports
- Front: Three USB 2.0, One USB 3.0 Mic/Headphone; Rear: Five USB 2.0, One USB 3.0, One Serial, Two PS2
- Input Devices
- Dell Entry keyboard;Dell USB Optical Mouse
- Power
- 80 Plus? Gold Certified, 90% efficient): 1300W
- Dimensions
- (HxWxD) 16.95" x 8.50" x 20.67"; 438mm x 216mm x 545mm
- Weight
- N/A
Dell Workstation Precision T5810 Xeon E5-1600v3 & E5-2600v3
- Κατηγορία
- Xeon E3, E5 v3 & v4 Series
- Operating System
- Windows 7 Home & Pro. MAR, Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- Intel C612 chipset
- Processors
- Intel? Xeon processor E5-1600 v3 Series plus select Intel Xeon E5-2600 v3
- Memory Support
- Quad channel;,Up to 256GB10 2133MHz DDR4 ECC RDIMM memory, 8 DIMM slots
- Hard Drive
- SATA or SSD
- Removable Media
- Optional
- Expansion Bays
- One external slimline optical bay; Two internal 3.5" hard drive bays; one external 5.25" bay
- Expansion Slots
- Two PCIe x16 Gen 3; one PCIe x16 Gen 3 wired x8 (HL); one PCIe x16 Gen 2 wired x4; one PCIe x1 Gen 2; One PCI 32bit
- Graphics
- Support for two PCI Express x16 Gen 2 or Gen 3 graphics cards up to 300W
- Audio
- Integrated: Realtek ALC3220 High Definition Audio
- Communications
- Integrated Intel I217 Gigabit Ethernet controller
- I/O Ports
- Front: Three USB 2.0, One USB 3.0, Mic/Headphone; Rear: Three USB 2.0, Three USB 3.0, Two PS2, One Serial
- Power
- 80 Plus? Gold Certified, 90% efficient): 685W or 425W
- Dimensions
- (HxWxD): 16.30 x 6.79 x 18.54"; 414 x 172.6 x 471mm
- Weight
- N/A
Dell Workstation Precision T5820 Xeon W2000 Family
- Κατηγορία
- Xeon Workstations
- Operating System
- Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- Intel? C422 - Intel X299
- Processors
- Intel? Xeon? Processor W-2000 Family and Core X Series CPUs with up to 18 cores and Intel Advanced Vector Extensions
- Memory Support
- Four channel memory up to 512GB 2666MHz and up to 256GB 2933MHz DDR4 (RDIMM) 8 DIMM slots
- Hard Drive
- Front accessible FlexBays support up to 4 x 2.5/3.5 SATA HDD/SSDs and up to 6 x 2.5 and 5 x 3.5 drives with 5.25 bay populated. Up to 2 front accessible (hot plug) M.2/U.2 NVMe PCIe SSDs
- Removable Media
- Slimline options: DVD-ROM; DVD+/-RW; BD-RE; Optional 5.25" device: DVD+/-RW
- Expansion Bays
- Two (2) FlexBays can support up to 2x 3.25 or2.5 drives each and (1) 5.25 HDD/SSD drives, One (1) Slimline
- Expansion Slots
- Two (2) PCIe x16, One (1) PCIe x16 wired as x8, One (1) PCie x16 wired as x4, One (1) PCIex16 wired as x1, One (1) PCI 32/33
- Graphics
- Support for two PCI Express x16 Gen 2 or Gen 3 graphics cards up to 300W
- Audio
- Integrated Realtek ALC3234 High Definition Audio
- Communications
- Intel? i219 Gigabit Ethernet controllers
- I/O Ports
- Front: Two (2) USB 3.1, Two (2) USB 3.1 Type-C, Mic/Headphone; Rear: Six (6) USB 3.1, Two (2) PS2, One (1) Serial, One (1) RJ45
- Input Devices
- USB Keyboard and Mouse
- Power
- 425W or 950W
- Dimensions
- 417.9 x 176.5 x 518.2 mm
- Weight
- 15.4 kg
Dell Workstation Precision T7810 Xeon E5
- Κατηγορία
- Xeon E3, E5 v3 & v4 Series
- Operating System
- Windows 7 Home & Pro. MAR, Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- Intel? C612 Chipset
- Processors
- One or two Intel? Xeon? processor E5-2600 v3 family with up to fourteen cores
- Memory Support
- Quad channel; Up to 256GB 2133 MHz DDR4 ECC RDIMM memory; 8 DIMM slots (4/processor)
- Hard Drive
- SATA 7200 RPM up to 4TB; SAS 15K up to 300GB; SAS 10K RPM up to 1.2TB; SSD up to 512GB
- Removable Media
- Slim-line tray load options: DVD-ROM; DVD+/-RW; Optional 5.25" device: DVD+/-RW; 19-in-1 media reader
- Expansion Bays
- One external slimline optical bay, two internal 3.5? hard drive bays, one external 5.25? bay;
- Expansion Slots
- Two PCIe x16 Gen 3; 1 PCIe x16 Gen 3 wired x8 (HL); 1 PCIe x4 Gen 2; 1 PCIe x1 gen2; one PCI 32 bit
- Graphics
- Support for two PCI Express? x16 Gen 2 or Gen 3 cards up to 300W
- Audio
- Integrated Realtek ALC269Q High Definition Audio
- Communications
- Intel I217 Gigabit Ethernet controllers
- I/O Ports
- Front: Three USB 2.0, One USB 3.0 Mic/Headphone; Rear: Three USB 2.0, Three USB 3.0, One Serial, Two PS2
- Input Devices
- Dell Entry keyboard;Dell USB Optical Mouse
- Power
- 80 Plus? Gold Certified, 90% efficient 825W or 685W
- Dimensions
- (HxWxD): 16.95 x 8.50 x 20.67"; 438 x 216 x 545mm
- Weight
- N/A
Dell Workstation Precision 7810 Xeon E5 series
- Κατηγορία
- Xeon E3, E5 v3 & v4 Series
- Operating System
- Windows 10 Pro for Workstations, Windows 10 Pro for Workstations Downgrade to Windows 7, Red Hat Linux, Suse Linux
- Chipset
- C612
- Processors
- One or two Intel Xeon processor E5-2600 v3 family
- Memory Support
- Up to 256GB 8 DIMM slots DDR4
- Hard Drive
- SATA or SSD
- Removable Media
- DVD ROM (optional)
- Expansion Bays
- N/A
- Expansion Slots
- 5 full-length slots, 1 half length, two PCIe x16 Gen 3; 1 PCIe x16 Gen 3 wired x8 (half-length); 1 PCIe x4 Gen 2; 1 PCIe x1 gen2; one PCI 32 bit/33MHz
- Graphics
- depending on model
- Audio
- N/A
- Communications
- Intel I217 Gigabit Ethernet
- I/O Ports 3 USB 2.0, 1 USB 3.0, 1 Microphone, 1 Headphone Internal
- 3 USB 2.0 internal, 1 serial, 1 RJ45
- Power
- 685W
- Dimensions
- 414 x 172.6 x 471mm
- Weight
- start at 13.50 kg
Dell Workstation Precision 7820 Xeon Silver & Gold
- Κατηγορία
- Xeon E3, E5 v5 & v6 Series
- Operating System
- Windows 10 Pro for Workstations, Windows 10 Pro for Workstations Downgrade to Windows 7, Red Hat Linux, Suse Linux
- Chipset
- Intel C621
- Processors
- One or two Intel Xeon processor Scalable family CPUs with up to 28 cores per processor.
- Memory Support
- 12 DIMM Slots (6 DIMMs per CPU) up to 384GB DDR4
- Hard Drive
- SATA or SSD
- Removable Media
- DVD ROM (optional)
- Expansion Bays
- 2 FlexBays and 1 5.25" Flexbay, 1 Slimline optical bay
- Expansion Slots
- (3) PCIe x16 Gen 3 [+(2) 2nd CPU]; (1) PCIe x16 Gen 3 (x4), (1) PCIe x16 Gen 3 (x1), (1) PCI 32Bit
- Graphics
- depending on model
- Audio
- Realtek ALC3234
- Communications
- Intel i219 Gigabit Ethernet
- I/O Ports
- Front: 2-USB 3.1 Gen 1 Type A, 2-USB 3.1 Type C, Rear: 6-USB 3.1 Gen 1 Type A, 1-Serial, 1-RJ45, 2-PS2
- Power
- 950W
- Dimensions
- H: 16.45" (41.78 cm), W: 6.94" (17.62 cm), D: 20.40" (51.81 cm)
- Weight
- N/A
