Xeon Series Workstations

HP Workstation XW6600 Xeon 5100 & 5200 & 5400

Περιορισμένα τεμάχια

Κατηγορία: Xeon 5400, 5500, 5600, 3500, 3600 & 2000 Series
Operating System: Windows 7 Home & Pro. MAR, Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
Chipset: Intel? 5400
Processors: Quad-Core Intel? Xeon? Processor 5400 or Dual-Core Intel? Xeon? Processor 5200
Memory Support: Eight (8) DIMM slots DDR2-667MHz FB-DIMM. Up to 32 GB Memory capacity
Hard Drive: 80GB to 1TB SATA 3.0-Gb/s, 73GB to 450GB SAS Drives
Removable Media: 16X DVD-ROM Drive, SATA 48X CD-RW/DVD-ROM Combo Drive, SuperMulti DVD+/-RW LightScribe Drive
Expansion Bays: External: Two (2) 5.25-inch, One (1) 3.5-inch, Internal: Two (2) 3.5-inch
Expansion Slots: 2 PCI Express x16 Gen2 Graphics Bus, 2 PCI, 2 PCI Express x8 (x4)
Graphics: N/A
Audio: High Definition Integrated Realtek ALC262 Audio
Communications: Integrated Broadcom 5755 Gigabit LAN
I/O Ports: Front: Two (2) USB 2.0, Headphone/Mic, Rear: Five (5) USB 2.0, 2 PS2, Serial, Audio I/O
Input Devices: Standard Keyboard (USB or PS/2)Mouse (USB or PS/2)
Power: 650 watt 80 PLUS high efficiency power supply
Dimensions: N/A
Weight: N/A

Περιορισμένα τεμάχια

Κατηγορία: Xeon 5400, 5500, 5600, 3500, 3600 & 2000 Series
Operating System: Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
Chipset: Intel X58 Express
Processors: Dual/Quad/Six Core Intel Xeon 3500/3600 Series Processors
Memory Support: 4-DIMM slots/ 6-DIMM slots (depending on base unit model) for PC3-10600 DDR3-1333 ECC memory
Hard Drive: 250GB to 2TB SATA 3.0-Gb/s, 300GB to 600GB SAS, 128GB to 256GB SSD Drives
Removable Media: 16X DVD-ROM SATA Drive, 16X DVD+/-RW SuperMulti SATA Drive, Blu-ray Writer
Expansion Bays: External: Three (3) 5.25-inch, Internal: Two (2) 3.5-inch
Expansion Slots: 2 PCIe x16 Gen2 Slots, 1 PCIe x4 Gen2, 1 PCIe x4 Gen1, 2 PCI Slots
Graphics: N/A
Audio: Integrated Intel/Realtek HD ALC262 Audio
Communications: Integrated Broadcom 5764 PCIe LOM Controller
I/O Ports: Front: Two (2) USB 2.0, Headphone/Mic, Rear: Six (6) USB 2.0, 2 PS2, Serial, Audio I/O
Input Devices: Standard Keyboard (USB or PS/2), Mouse (USB or PS/2)
Power: 475W, 85% efficient Power Supply
Dimensions: 45.53 x 45 x 16.79 cm
Weight: 15.1 kg

Περιορισμένα τεμάχια

Κατηγορία: Xeon 5400, 5500, 5600, 3500, 3600 & 2000 Series
Operating System: Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
Chipset: Intel C422
Processors: Intel Xeon W Processors
Memory Support: 8 DIMM slots, DDR4-2666 ECC Registered RAM, Supports up to 512GB
Hard Drive: HDD or SSD
Removable Media: N/A
Expansion Bays: 2 x 5.25” external drive bays, 2 x 2.5”/3.5” internal drive bays
Expansion Slots: 2 PCIe G3 x16, 2 PCIe G3 x4, 1 PCIe G3 x8, 2 PCIe G3 x4 M.2 for SSDs
Graphics: Depending on model
Audio: Realtek ALC221
Communications: Intel Ethernet I210-T1 PCIe x1 Gb NIC
I/O Ports: Front: 4x USB 3.1 G1 Type A, Headset, Internal I/O ports : 1 USB 3.1 G1, 2 USB 2.0, Rear I/O ports : 6x USB 3.1 G1 Type-A, RJ-45, Line out, Line in, PS/2 mouse, PS/2 keyboard
Power: 465 W, 750 W or 1000W
Dimensions: 445mm x 169mm x 386mm
Weight: 10.2 kg - 17.3 kg

Περιορισμένα τεμάχια

Κατηγορία: Xeon 5400, 5500, 5600, 3500, 3600 & 2000 Series
Operating System: Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
Chipset: Intel C422, Intel X299
Processors: Intel Xeon Processor W-2000 Family, Core X Series
Memory Support: Four channel memory up to 512GB 2666MHz and up to 256GB 2933MHz DDR4 (RDIMM) ECC memory. (Up to 256GB 2666MHz DDR4 (UDIMM) Non-ECC memory) 8 DIMM slots
Hard Drive: HDD, SSD, M.2 NVMe
Removable Media: N/A
Expansion Bays: 2) FlexBays can support up to 2x 3.25” or 2.5” drives each and (1) 5.25” HDD/SSD drives as factory option or customer kit
Expansion Slots: All slots PCIe Gen 3: (2) PCIe x16, (1) PCIe x16 wired as x8, (1) PCie x16 wired as x4, (1) PCIe x16 wired as x1, 1 PCI 32/33
Graphics: Radeon Pro, NVIDIA Quadro
Audio: Integrated Realtek ALC3234 High Definition Audio Codec (2 Channel)
Communications: Integrated: Intel® i219 Gigabit Ethernet controllers with Intel Remote Wake UP, PXE and Jumbo frames support
I/O Ports: Front: 2 x USB 3.1 Gen 1 Type A, 2 x USB 3.1 Gen 1 Type C, Universal Headphone Jack, Internal: 1 x USB 2.0 Type A, 1 x 2x5 USB 2.0 header. (requires 3rd party splitter cable to support 2 x USB 2.0 Type A ports), SATA
, Rear: 6 x USB 3.1 Gen 1 Type A (6th port supports Power Delivery), Serial, RJ45, Audio Line out, Audio Line in/Microphone
Power: 425W or 950W
Dimensions: 417.9 x 176.5 x 518.2 mm
Weight: Starting at 15.4kg
