Lenovo ThinkStation P320 SFF i5, i7 7th Gen

Available

Category: Core i3,i5,i7 6th & 7th Gen
Operating System: Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
Chipset: Intel C236
Processors: Intel Core i3, i5, i7 6th & 7th Gen, Intel Xeon
Memory Support: Four (4) DIMM slots , Up to 64 GB DDR4
Hard Drive: 3.5" SATA HDD (7.2K 6Gbs), 2.5" SATA SSD (6Gbs), M.2 NVMe SSD, via PCIe adapter
Removable Media: N/A
Expansion Bays: One (1) external 5.25" bay, one (1) internal 3.5" bay
Expansion Slots: Slot 1: Low Profile,PCIe 3.0 x16 (near CPU), Slot 2: Low Profile,PCIe 3.0 x1, Slot 3: Low Profile,PCIe 3.0 x16 (x4 elec), Slot 4: Low Profile,PCIe 3.0 x1
Graphics: Intel HD Graphics depending on the processor (P530 or P630 or 530 or 630)
Audio: High Definition Audio Realtek ALC662 codec
Communications: One onboard gigabit ethernet, Intel I219LM, supports Wake-on-LAN
I/O Ports: Front: Two (2) USB 3.0, microphone, headphone Rear: 1 VGA and 2 DisplayPort (for Intel HD Graphics models only), two USB 2.0, four USB 3.0, one serial (9-pin), one ethernet (RJ-45), three analog audio ports (line-in, line-out, mic-in)
Power: 80 PLUS Bronze 210 watts
Dimensions: 102mm X 394.5mm X 338mm
Weight: 7.9 kg

Lenovo ThinkStation P310 MT Core i7 6th Gen

Limited items

Category: Core i3,i5,i7 6th & 7th Gen
Operating System: Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
Chipset: Intel C236 Chipset
Processors: Intel i7 6th generation
Memory Support: Up to 64GB ECC/non-ECC (4 x 16GB), 2133MHz DDR4
Hard Drive: HDD or SSD
Graphics: Intel HD 530
Audio: Realtek ALC662 codec
Communications: One onboard gigabit ethernet, Intel I219LM, supports Wake-on-LAN
Ports: Front: Two USB 3.0, microphone, headphone, Rear: 1 VGA and 2 DisplayPort (for Intel HD Graphics models only), two USB 2.0, four USB 3.0 (blue), one serial (9-pin), one ethernet (RJ-45), three analog audio ports (line-in, line-out, mic-in)
Power: 250W or 400W
Dimensions: 175 x 426 x 376 mm
Weight: 13 kg

Limited items

Category: Core i3,i5,i7 6th & 7th Gen
Operating System: Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
Chipset: Intel PCH C236
Processors: Core i3/i5/i7-6xxx processors, Xeon E3 processors
Memory Support: 4 DDR4 memory slots, DDR4, Max 64 GB
Hard Drive: SATA or SSD
Removable Media: N/A
Expansion Bays: 1 shared internal/external 3.5" bay, 1 internal 3.5" bay, 1 internal 2.5" bay (for SSD only)
Expansion Slots: 1 PCIe Gen3 x16, 1 PCIe Gen3 x4 (x4 connector), 1 PCIe Gen3 x4 (x16 connector), 1 PCIe Gen3 x1, 1 PCI (optional), 1 M.2 PCIe Gen3 x4
Graphics: Intel Integrated Graphics for Xeon processors
Audio: Integrated Realtek HD ALC221-VB audio
Communications: Integrated Intel I219LM PCIe GbE
I/O Ports: Front: 2 USB 3.0, 2 USB 2.0 (1 charging), 1 headphone; 1 microphone, Back: 4 USB 3.0, 2 USB 2.0, 2 DisplayPort 1.2,1 DVI-I single link, 1 serial (optional); 1 parallel (optional), 2 PS/2; 1 RJ-45; 1 audio line-in; 1 audioline-out
Power: 400 W 92% efficient, wide-ranging, active PFC, 280 W 90% efficient, wide-ranging, active PFC
Dimensions: 170 x 442 x 399 mm
Weight: Starting at 8.6 kg
