Lenovo ThinkStation S20 Xeon W3503
Limited items
- Category
- Xeon E3, E5 v1 & v2 Series
- Operating System
- Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- Intel Tylersburg 36D & Intel ICH10
- Processors
- Intel Xeo Dual Core & Intel Xeon Quad Core
- Memory Support
- Six (6) slots, DDR3 Unbuffered SDRAM
- Hard Drive
- Up to 1 TB SATA 7200 rpm or SSD (optional)
- Removable Media
- DVD-ROM/ DVD-ReWritable
- Expansion Bays
- External: One (1) 5.25-inch, Internal: Three (3) 3.5-inch
- Expansion Slots
- Two (2) PCI Express x16 height length, One (1) PCI Express 2.0 x4 height length, , One (1) PCI x1 height length, One (1) PCI half length
- Graphics
- Integraded with processor
- Audio
- Analog Devices AD1988A
- Communications
- Integrated Gigabit Ethernet
- I/O Ports
- Front: Two (2) USB 2.0 , Audio I/O , Rear: Eight (8) USB 2.0, RS232, RJ45, Esata,Audio ports
- Power
- 625 W
- Dimensions
- 48.8 x 47.8 x 17.5 cm
- Weight
- 17.5kg
HP Workstation Z210 i3,i5,i7 2nd Gen & E3-1200
Limited items
- Category
- Xeon E3, E5 v1 & v2 Series
- Operating System
- Windows 7 Home & Pro. MAR, Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- Intel? PCH C206
- Processors
- Intel? Xeon? processor E3 family, 2nd gen Intel? Core? processor family, Dual-Core Intel Pentium processors
- Memory Support
- Four (4) DIMM slots for DDR3 PC3-10600 ECC, 16GB Max
- Hard Drive
- 250GB to 2TB SATA 3.0-Gb/s, 160GB to 256GB SSD Drives
- Removable Media
- 16X DVD-ROM SATA Drive, 16X DVD+/-RW SuperMulti SATA Drive, Blu-ray Writer
- Expansion Bays
- External: Three (3) 5.25-inch, Internal: Three (3) 3.5-inch
- Expansion Slots
- 1 PCIe x16 Gen2 Slot, 1 PCIe x16 Gen2 (x4), 1 PCIe x8 Gen2 (x4), 2 PCIe x1 Gen1, 2 PCI Slots
- Graphics
- Intel Integrated Graphics Media Accelerator HD
- Audio
- Integrated Intel/Realtek HD ALC262 Audio
- Communications
- Intel Gigabit CT Desktop NIC
- I/O Ports
- Front: Three (3) USB 2.0, Headphone/Mic, Rear: Six (6) USB 2.0, 2 PS2, Serial, Audio I/O, DVI-I, DP
- Input Devices
- Standard Keyboard (USB or PS/2)Mouse (USB or PS/2)
- Power
- 400 watts wide-ranging, active Power Factor Correction, 90% Efficient
- Dimensions
- 447 x 178 x 455 mm (17.6 x 7 x 17.9 in)
- Weight
- 11.7 kg (25.8 lbs)
Dell Workstation Precision T1650 E3-1200v2
Limited items
- Category
- Tower
- Operating System
- Windows 7 Home & Pro. MAR, Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- Intel C216 Chipset
- Processors
- Intel? Xeon? Processor E3-1200v2 Family; 3rd generation Intel? Core? i7 and i5; 2nd generation Intel Core i3
- Memory Support
- Up to 32GB 1600MHz ECC or 16GB non-ECC DDR3 memory; 4 DIMM slots
- Hard Drive
- Up to two 3.5" SATA drives: 250GB, 500GB, 1TB, 2TB; Or up to four 2.5" SATA drives: 320GB, 500GB
- Removable Media
- Up to two optional optical drives: DVD-ROM; DVD+/-RW; BD-RE
- Expansion Bays
- Two internal 3.5" hard drive bays; two external 5.25" optical bays
- Expansion Slots
- One PCIe x16 Gen 3; one PCIe x16 Gen 2 wired x4; one PCIe x1; One PCI 32bit/33MHz
- Graphics
- Support for one PCI Express? x16 Gen 3 graphic card up to 75W (total for graphics)
- Audio
- Integrated Realtek ALC269VB High Definition Audio
- Communications
- Integrated Intel 82579 Gigabit Ethernet controller
- I/O Ports
- Front: Two USB 2.0, Two USB 3.0, Mic/Headphones; Rear: Four USB 2.0, Two USB 3.0, VGA, DP, Serial. Two PS2, Audio I/O
- Power
- 320W 90% efficient (80 Plus? Gold Certified); 275W 65% efficient
- Dimensions
- (HxWxD) 14.17" x 6.89" x 17.13"; 360mm x 175mm x 435mm
- Weight
- N/A
HP Workstation Z420 Xeon E5-1600, E5-1600v2, E5-2600v2
Available
- Category
- Tower
- Operating System
- Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- Intel X58 Express
- Processors
- Intel Xeon Processors: E5-1600 family (4C), E5-1600v2 family (4C/6C/8C), E5-2600v2 (8C)
- Memory Support
- 8 DIMM Slots for DDR3 ECC Memory
- Hard Drive
- 250GB to 2TB SATA 3.0-Gb/s, 300GB to 600GB SAS, 128GB to 256GB SSD Drives
- Removable Media
- 16X DVD-ROM SATA Drive, 16X DVD+/-RW SuperMulti SATA Drive, Blu-ray Writer
- Expansion Bays
- External: Three (3) 5.25-inch, Internal: Three (3) 3.5-inch
- Expansion Slots
- 2 PCIe x16 Gen3 Slots, 1 PCIe x8 Gen3, 1 PCIe x8(x4) Gen2, 1 PCIe x4(x1) Gen2, 1 PCI Slot
- Graphics
- N/A
- Audio
- Integrated Intel/Realtek HD ALC262 Audio
- Communications
- Integrated Intel 82579LM PCIe GbE Controller
- I/O Ports
- Front: 1 USB 2.0, 2 USB 3.0, Headphone/Mic, Rear: 4 USB 2.0, 2 USB 3.0, 2 PS2, Audio I/O
- Power
- 600W
- Dimensions
- 44.76 x 17.78 x 44.52 cm
- Weight
- 13.2kg
Dell Workstation Precision T5610 Xeon E5-2600v2
Limited items
- Category
- Tower
- Operating System
- Windows 7 Home & Pro. MAR, Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- Intel? C602
- Processors
- One or two; Intel? Xeon? processor E5-2600 v2 family with up to ten cores
- Memory Support
- Quad channel; Up to 128GB 1866MHz ECC RDIMM memory; 8 DIMM slots (4 per processor)
- Hard Drive
- SATA 7200RPM Up to 3TB, SAS 10K RPM Up to 900GB, SSD Up to 512GB
- Removable Media
- Slimline options: DVD-ROM; DVD+/-RW; BD-RE; Optional 5.25" device: DVD+/-RW, 19-in-1 media card reader
- Expansion Bays
- One external slimline optical bay; Two internal 3.5" hard drive bays; one external 5.25" bay
- Expansion Slots
- Two PCIe x16 Gen 3; one PCIe x16 Gen 3 wired x8 (HL); one PCIe x16 Gen 2 wired x4; one PCIe x1 Gen 2; One PCI 32bit
- Graphics
- Support for two PCI Express? x16 Gen 2 or Gen 3 graphics cards up to 300W
- Audio
- Integrated Realtek ALC269Q High Definition Audio
- Communications
- Intel 82579 Gigabit Ethernet controller
- I/O Ports
- Front: Three USB 2.0, One USB 3.0, Mic/Headphone; Rear: Three USB 2.0, Three USB 3.0, Two PS2, One Serial
- Input Devices
- USB: Dell QuietKey, Enhanced Multimedia, Smartcard Reader keyboard; Bluetooth Keyboard and Mouse
- USB
- Dell two-button mechanical with scroll, Dell two-button optical with scroll
- Power
- 80 Plus? Gold Certified, 90% efficient): 825W or 685W
- Dimensions
- (HxWxD): 16.30 x 6.79 x 18.54"; 414 x 172.6 x 471mm
- Weight
- N/A
Dell Workstation Precision T3600 E5-1600 & E5-2600
Limited items
- Category
- Tower
- Operating System
- Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- Intel C600 series chipset
- Processors
- Intel Xeon processor E5-1600 or E5-2600 family with up to eight-cores
- Memory Support
- Quad channel; Up to 64GB 1600MHz or 1333MHz ECC and non-ECC DDR3 memory; 4 DIMM slots
- Hard Drive
- SATA 7200RPM Up to 3.0TB, SSD Up to 256GB
- Removable Media
- Slimline options: DVD-ROM; DVD+/-RW; BD-RE; Optional 5.25" device: DVD+/-RW, 19-in-1 media card reader
- Expansion Bays
- Two internal 3.5" hard drive bays; one external 5.25" bay; one external slimline optical bay
- Expansion Slots
- Two PCIe x16 Gen 3; one PCIe x16 Gen 3 wired x4; one PCIe x4 Gen 2; one PCIe x1 Gen 2; One PCI 32bit/33MHz
- Graphics
- Support for two PCI Express? x16 Gen 2 or Gen 3 graphics cards up to 300W
- Audio
- Integrated Realtek ALC269Q High Definition Audio
- Communications
- Integrated Intel 82579 Gigabit Ethernet controller
- I/O Ports
- Front three USB 2.0, One USB 3.0, Mic/Headphone; Rear: Five USB 2.0, One USB 3.0, One Serial, Two PS2
- Input Devices
- USB: Dell QuietKey, Enhanced Multimedia, Smartcard Reader keyboard; Bluetooth Keyboard and Mouse, USB: Dell two-button mechanical with scroll, Dell two-button optical with scroll
- Power
- 80 Plus Gold Certified, 90% efficient): 635W or 425W
- Dimensions
- 414 x 471 x 172.6 mm
- Weight
- N/A
Dell Workstation Precision T7600 Xeon E5-2600
Limited items
- Category
- Tower
- Operating System
- Windows 7 Home & Pro. MAR, Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- Intel? C600 series
- Processors
- One or two; Intel? Xeon? processor E5-2600 family with up to eight cores
- Memory Support
- Quad channel; up to 512GB 1600MHz or 1333MHz ECC RDIMM memory; 16 DIMM slots (8 per processor)
- Hard Drive
- SATA 7200 RPM up to 3TB; SAS 15K up to 146GB; SAS 10K RPM up to 900GB; SSD up to 256GB
- Removable Media
- CD-RW/DVD Combo, DVD-ROM, DVD+/-RW, Blu-ray, USB Floppy Drive, USB media card reader
- Expansion Bays
- One external slimline optical bay; One external 5.25" bay; Four 3.5" or eight 2.5" hard drive bays;
- Expansion Slots
- Two PCIe x16; two additional PCIe x16; one PCIe x16 (x4); one PCIe x16 Gen 2 (x4); One PCI 32bit
- Graphics
- Support for up to three PCI Express? x16 Gen 2 or Gen 3 graphics cards up to 675W
- Audio
- Integrated Realtek ALC269Q High Definition Audio
- Communications
- Integrated Intel 82579 and Intel 82754 Gigabit Ethernet controllers
- I/O Ports
- Front: Three USB 2.0, One USB 3.0 Mic/Headphone; Rear: Five USB 2.0, One USB 3.0, One Serial, Two PS2
- Input Devices
- Dell Entry keyboard;Dell USB Optical Mouse
- Power
- 80 Plus? Gold Certified, 90% efficient): 1300W
- Dimensions
- (HxWxD) 16.95" x 8.50" x 20.67"; 438mm x 216mm x 545mm
- Weight
- N/A
HP Workstation Z620 Xeon E5-1600, E5-2600
Limited items
- Category
- Tower
- Operating System
- Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- Intel C602
- Processors
- Intel Xeon E5-2600, Intel Xeon E5-2600 v2, Intel Xeon E5-1600, Intel Xeon E5-1600 v2
- Memory Support
- 12 DIMM Slots for DDR3 ECC, 4-channel per processor 1066/1333/1600/1866 MHz DDR3, Up to 192GB
- Hard Drive
- 250GB to 3TB SATA 3.0-Gb/s, 300GB to 1.2TB SAS, 128GB to 512GB SSD Drives
- Removable Media
- DVD-ROM/ DVD-ReWritable
- Expansion Bays
- External: Two (2) 5.25-inch, Internal: Three (3) 3.5-inch
- Expansion Slots
- 2 PCIe x16 Gen3 Slots, 1 PCIe x8 Gen3, 1 PCIe x8(x4) Gen2, 1 PCIe x4(x1) Gen2, 1 PCI Slot
- Graphics
- N/A
- Audio
- Integrated Intel/Realtek HD ALC262 Audio
- Communications
- Integrated Intel 82579LM PCIe GbE Controller
- I/O Ports
- Front: 1 USB 2.0, 2 USB 3.0, Headphone/Mic, Rear: 4 USB 2.0, 2 USB 3.0, 2 PS2, Audio I/O
- Input Devices
- Standard Keyboard (USB or PS/2)Mouse (USB or PS/2)
- Power
- 800W
- Dimensions
- 44.45 x 17.15 x 46.48 cm
- Weight
- 17.9 kg
HP Workstation Z820 Xeon E5
Limited items
- Category
- Tower
- Operating System
- Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- Intel C602
- Processors
- Intel Xeon E5-2600 Series, Intel Xeon E5-2600 v2 Series
- Memory Support
- 16 slots (8 slots per CPU), 3-channel DDR3, RDIMM or UDIMM, ECC, LR DIMMs,1066/1333/1600 MT/s
- Hard Drive
- 250GB to 3TB SATA 3.0-Gb/s, 300GB to 1.2TB SAS, 128GB to 1TB SSD Drives
- Removable Media
- 16X DVD-ROM SATA Drive, 16X DVD+/-RW SuperMulti SATA Drive, Blu-ray Writer
- Expansion Bays
- External: Three (3) 5.25-inch, Internal: Four (4) 3.5-inch
- Expansion Slots
- 3 PCIe x16 Gen3 Slots (3rd on 2nd CPU), PCIe x16 (x8)(on 2nd CPU), 1 PCIe x8(x4), 1 PCIe x8(x4), 1 PCI Slot
- Graphics
- N/A
- Audio
- Integrated Intel/Realtek HD ALC262 Audio
- Communications
- Integrated Intel 82579LM PCIe GbE Controller
- I/O Ports
- Front: 1 USB 2.0, 2 USB 3.0, Headphone/Mic, Rear: 4 USB 2.0, 2 USB 3.0, 2 PS2, 1 Serial, Audio I/O
- Input Devices
- Standard Keyboard (USB or PS/2)Mouse (USB or PS/2)
- Power
- Choice of 850W
- Dimensions
- 44.4 x 20.3 x 52.5 cm
- Weight
- 21 kg
HP Workstation Z2 G4 Tower Intel Xeon
Limited items
- Category
- Xeon E3, E5 v1 & v2 Series
- Operating System
- Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- IIntel C246
- Processors
- Intel Xeon or i7 8th Gen
- Memory Support
- DDR4 memory up to 2666 MT/s data rate
- Hard Drive
- HDD or SSD
- Removable Media
- Optional
- Expansion Bays
- (2) External 13.3 cm (5.25 in) bays, (2) External 13.3 cm (5.25 in) bays
- Expansion Slots
- (1) PCIe Gen3 x16 slot, (1) PCIe Gen3 x4 slot/x16 connector, (1) PCIe Gen3 x1 slot/x4 connector, (1) PCIe Gen3 x1 slot/x4 connector, (2) M.2 storage (PCIe Gen3 x4)
- Graphics
- Depending on model
- Audio
- Conexant CX20632 5.1 HDA codec
- Communications
- Intel I350-T2 2-Port 1GbE NIC
- I/O Ports
- Front: (2) x USB 3.0, (1) x USB 3.1 Back: (2) χ DisplayPort, (2) χ USB 2.0 ports (4)x USB 3.0 ports, (1) RJ-45, Internal I/O ports : (1) USB 3.0 port, (2) USB 2.0 ports
- Power
- 250 W or 500W or 650W
- Dimensions
- 356 x 169 x 435 mm
- Weight
- Starting at 8.2 kg
