CPU Type AMD Opteron 6300 Series
ChipSet AMD SR5690 and SP5100
CPU Socket G34
CPU No 2
RAM Support (max) Maximum (LRDIMM) 512GB (16 x 32GB) at 1333MHz, Maximum (RDIMM) 256GB (16 x 16GB) up to 1600MHz
RAM Slots 16
RAM Type PE SmartMemory DDR3 Load Reduced (LRDIMM) or Registered (RDIMM)
HDD bays Two (2) small form factor (SFF) hot plug drive bays
Internal Storage (max) 3.2 TB
On board network One (1) FlexibleLOM connector for one dual-port FlexibleLOM,
Expansion slots 2 x mezzanine I/O expansion slots, One (1) 10/100 Mbps port for the HPE iLO 4 On System Management Chipset, One (1) 10/100 Mbps port for the HPE iLO 4 to Onboard Administrator link. The Onboard Administrator (with 10/100/1000 Mbps) to BladeSystem link is 1Gbps.
Internal Raid Controllers HPE Smart Array P220i Controller with 512MB FBWC
