Wireless function2.4G or 2.4G+Bluetooth for option
Battery3.7V/2500mAh (20000 times scan and transmission)
Prompting ModeLED / buzzer
Working Voltage+4.2V±10% VDC
Working current226mA
Starting Current204mA
Standby current96mA
Shock SpecificationsDesigned to withstand 1.5m drops
IlluminationWhite LED
AimingRed LED
Image sensorCMOS
Image resolution640*480
Print contrast≥ 20% minimum reflective difference
scan angleRoll/Pitch/Yaw:65°（Yaw）,65°（Pitch）,360°（Roll）
WeightGross:290g
Working temperature& humidity0 to 45 degrees centigrade, 10%~80% No condensation
Storage temperature& humidity-20 to 60 degrees centigrade , 10%~90% No condensation
