INPUT
Nominal Voltage 200/208/220/230/240 VAC
Voltage range 110-300 VAC +- 5% 50% load, 160-300 VAC +- 5% 100% load
Frequency range 40 - 70 HzTotal Harmonic Distortion (THDi) <= 5% nominal input voltage
Power factor >= 0.99 nominal voltage (100% load)
OUTPUT
Output Voltage 200*/208*/220/230/240 VAC
AC Voltage Regulation = +- 1%
Frequency Range 57 ~ 63 Hz or 47 ~ 53 Hz
Current Crest Ratio 3:1 max
Harmonic Distortion <= 2 % THD (Linear Load), <= 4 % THD (Non-linear load)
Transfer Time AC mode to Battery mode= Zero, Inverter to Bypass= 4 ms (Typical)
Waveform Pure Sinewave
Overload 110-130% 5 min / 130-140% 30 sec / >140% 1.5 sec to 100ms
Outlets 8 x IEC 320 C13
EFFICIENCY
AC Mode >= 90% full charged battery
ECO Mode >=96% @ full charged battery
Battery Mode >= 88%
BATTERIES
Battery Type (VRLA) 12 V / 9 AH
Numbers 6
Typical Recharge Time 3 hours recover to 95% capacity for internal battery 2A charging current
Charging Current Default 2A, max. 12A adjustable
Charging Voltage 54.8 VDC -+ 1%
PHUSICAL
Dimension, D x W x H (mm) 510 x 438 x 88
Net Weight (without battery) (kgs) 9.4
Net Weight (w/built-int battery) (kgs) 19.5
ENVIRONMENT
Humidity 5-95 % RH , 0- 40 (non-condensing)
Noise Level Less than 50dBA, 1 Meter
Altitude 10% de-rating for over 1000m (The altitude should not exceed 3000m)
MANAGMENT
Smart RS-232/USB & Softwarel Supports Windows 2000/2003/ XP/ Vista/ 2008/ 7/ 8, Linux and MAC
Optional SNMPl Power management from SNMP manager and web browser
STANDARD
EMC/safety EMC EN62040-2 C2 / EN 62040 - 1 / EN 62040 ? 3 / RoHS 2
