Dell Workstation Precision T3500 Xeon 3500 & 5600
Limited items
- Category
- Xeon 5400, 5500, 5600, 3500 &3600 Series
- Operating System
- Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- Intel X58
- Processors
- Intel Xeon 5600 series processors up to six-cores with up to 6.4GT/s
- Memory Support
- Up to 24GB 1333MHz ECC and non-ECC memory in 6 DIMM slots
- Hard Drive
- SATA 3.0GB/s 7200RPM SATA 3.0GB/s 10K RPM Up to 2.0TB
- Removable Media
- CD-RW/DVD Combo; DVD-ROM; DVD+/-RW; Blu-ray; USB Floppy Drive; USB media card reader
- Expansion Bays
- Two internal 3.5" HDD bays; two external 5.25" optical bays, one external 3.5" flex bay
- Expansion Slots
- Two PCIe x8 slot wired as x4 (half-length); two PCIe x16 Gen 2 graphics slots; two PCI slots
- Graphics
- Support for 2 PCI Express x16 Gen 2 graphics cards up to 150W.
- Audio
- Integrated High Definition Audio
- Communications
- Integrated Broadcom? 5761 Gigabit Ethernet controller
- I/O Ports
- Eleven USB 2.0: two front, six rear, three internal; One serial; One parallel; Two PS/2; Mic and headphone, line-in and line-out
- Input Devices
- USB: Dell QuietKey, Enhanced Multimedia, Smartcard Reader keyboard; Bluetooth Keyboard and Mouse
- USB
- Dell two-button mechanical with scroll, Dell two-button optical with scroll
- Power
- 525W
- Dimensions
- 44.7 x 17.2 x 46.8 cm
- Weight
- N/A
Dell Workstation Precision T7400 Xeon 5200 & 5400
Limited items
- Category
- Xeon 5400, 5500, 5600, 3500 &3600 Series
- Operating System
- Windows 7 Home & Pro. MAR, Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- Intel? 5400 chipset
- Processors
- Dual-core Intel? Xeon? 5200 series processors; Quad-core Intel? Xeon? 5400 series processors;
- Memory Support
- Up to 64GB1 quad-channel 667MHz ECC and 800MHz ECC memory; Up to 16 DIMM slots;
- Hard Drive
- SATA 3.0Gb/s 7200 RPM 16MB up to 1.0TB; SATA 3.0Gb/s 10K RPM 16MB up to 160GB; SAS 15K RPM up to 300GB
- Removable Media
- CD-RW/DVD Combo, DVD-ROM, DVD+/-RW, Blu-ray, USB Floppy Drive, USB media card reader
- Expansion Bays
- Four internal 3.5? hard disk drive bays; Three external 5.25? optical bays; One external 3.5? flex bay
- Expansion Slots
- One PCI-e x8 slot wired as x4; Two PCI-e x16 Gen 2 slots; Three PCI-X 64bit/100MHz slots, One PCI 32bit slot;
- Graphics
- Support for 2 PCI Express x16 Gen 2 graphics cards up to 225 watts
- Audio
- Integrated High Definition Audio
- Communications
- Integrated Broadcom? 5754 Gigabit Ethernet controller
- I/O Ports
- Front: Two USB 2.0, Mic/Headphone; Rear: Five USB 2.0, Two PS2, Two Serial, Audio I/O
- Input Devices
- Dell Enhanced QuietKey USB; Enhanced Multimedia USB; Smart Card keyboard USBDell USB two-button mouse and Dell USB optical two-button scroll mouse
- Power
- 980 watt 80%+ Efficiency Power Factor Correcting (PFC) power supply
- Dimensions
- (WxHxD) 8.5? x 22.26? x 22.3?, 21.59cm x 56.54cm x 56.6cm
- Weight
- N/A
HP Workstation Z400 Xeon 3500 & 3600
Available
- Category
- Xeon 5400, 5500, 5600, 3500 &3600 Series
- Operating System
- Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- Intel X58 Express
- Processors
- Dual/Quad/Six Core Intel Xeon 3500/3600 Series Processors
- Memory Support
- 4-DIMM slots/ 6-DIMM slots (depending on base unit model) for PC3-10600 DDR3-1333 ECC memory
- Hard Drive
- 250GB to 2TB SATA 3.0-Gb/s, 300GB to 600GB SAS, 128GB to 256GB SSD Drives
- Removable Media
- 16X DVD-ROM SATA Drive, 16X DVD+/-RW SuperMulti SATA Drive, Blu-ray Writer
- Expansion Bays
- External: Three (3) 5.25-inch, Internal: Two (2) 3.5-inch
- Expansion Slots
- 2 PCIe x16 Gen2 Slots, 1 PCIe x4 Gen2, 1 PCIe x4 Gen1, 2 PCI Slots
- Graphics
- N/A
- Audio
- Integrated Intel/Realtek HD ALC262 Audio
- Communications
- Integrated Broadcom 5764 PCIe LOM Controller
- I/O Ports
- Front: Two (2) USB 2.0, Headphone/Mic, Rear: Six (6) USB 2.0, 2 PS2, Serial, Audio I/O
- Input Devices
- Standard Keyboard (USB or PS/2), Mouse (USB or PS/2)
- Power
- 475W, 85% efficient Power Supply
- Dimensions
- 45.53 x 45 x 16.79 cm
- Weight
- 15.1 kg
HP Workstation XW6600 Xeon 5100 & 5200 & 5400
Limited items
- Category
- Xeon 5400, 5500, 5600, 3500 &3600 Series
- Operating System
- Windows 7 Home & Pro. MAR, Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- Intel? 5400
- Processors
- Quad-Core Intel? Xeon? Processor 5400 or Dual-Core Intel? Xeon? Processor 5200
- Memory Support
- Eight (8) DIMM slots DDR2-667MHz FB-DIMM. Up to 32 GB Memory capacity
- Hard Drive
- 80GB to 1TB SATA 3.0-Gb/s, 73GB to 450GB SAS Drives
- Removable Media
- 16X DVD-ROM Drive, SATA 48X CD-RW/DVD-ROM Combo Drive, SuperMulti DVD+/-RW LightScribe Drive
- Expansion Bays
- External: Two (2) 5.25-inch, One (1) 3.5-inch, Internal: Two (2) 3.5-inch
- Expansion Slots
- 2 PCI Express x16 Gen2 Graphics Bus, 2 PCI, 2 PCI Express x8 (x4)
- Graphics
- N/A
- Audio
- High Definition Integrated Realtek ALC262 Audio
- Communications
- Integrated Broadcom 5755 Gigabit LAN
- I/O Ports
- Front: Two (2) USB 2.0, Headphone/Mic, Rear: Five (5) USB 2.0, 2 PS2, Serial, Audio I/O
- Input Devices
- Standard Keyboard (USB or PS/2)Mouse (USB or PS/2)
- Power
- 650 watt 80 PLUS high efficiency power supply
- Dimensions
- N/A
- Weight
- N/A
HP Workstation Z800 Xeon 5500 & 5600
Limited items
- Category
- Xeon 5400, 5500, 5600, 3500 &3600 Series
- Operating System
- Windows 7 Home & Pro. MAR, Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
- Chipset
- Intel? 5520
- Processors
- Four-Core and Six-Core Intel Xeon Processor 5600 Series
- Memory Support
- 12 DIMM Slots for DDR3 ECC, 3-channel 800/1066/1333 MHz DDR3, Up to 192GB
- Hard Drive
- 250GB to 3TB SATA 3.0-Gb/s, 300GB to 600GB SAS, 128GB to 300GB SSD Drives
- Removable Media
- 16X DVD-ROM SATA Drive, 16X DVD+/-RW SuperMulti SATA Drive, Blu-ray Writer
- Expansion Bays
- External: Three (3) 5.25-inch, Internal: Four (4) 3.5-inch
- Expansion Slots
- 2 PCIe x16 Gen2 Slots, 2 PCIe x8 Gen2, 1 PCIe x4 Gen2, 1 PCIe x4 Gen1, 1 PCI Slot
- Graphics
- N/A
- Audio
- High Definition integrated audio with internal speaker
- Communications
- Dual integrated Broadcom 5764 Gigabit LAN
- I/O Ports
- Front: Three (3) USB 2.0, Headphone/Mic, Rear: Six (6) USB 2.0, 2 PS2, 1 Serial, Audio I/O
- Power
- Choice of 850W, 85% or 1110W, 89% Power Supplies
- Dimensions
- 44.4 x 20.3 x 52.5 cm; 17.5 x 8.0 x 20.7 inches
- Weight
- 21 kg (46 lb)
